ASME A112.19.1 pdf download Enamelled cast iron and enamelled steel plumbing fixtures
1 Scope
1.1
This Standard covers enamelled cast iron and enamelled steel plumbing fixtures and specifies requirements for materials, construction, performance, testing, and markings.
1.2
This Standard covers the following plumbing fixtures:
(a) bathtubs;
(b) drinking fountains and water coolers;
(c) lavatories;
(d) shower bases; and
(e) sinks:
(i) kitchen and bar sinks;
(ii) laundry sinks;
(iii) service sinks; and
(iv) utility sinks.
1.3
In this Standard, “shall” is used to express a requirement, i.e., a provision that the user is obliged to satisfy in order to comply with the standard; “should” is used to express a recommendation or that which is advised but not required; “may” is used to express an option or that which is permissible within the limits of the standard; and “can” is used to express possibility or capability. Notes accompanying clauses do not include requirements or alternative requirements; the purpose of a note accompanying a clause is to separate from the text explanatory or informative material. Notes to tables and figures are considered part of the table or figure and may be written as requirements. Annexes are designated normative (mandatory) or informative (non-mandatory) to define their application.
1.4 SI units are the units of record in Canada. In this Standard, the yard/pound units are shown in parentheses. The values stated in each measurement system are equivalent in application; however, each system is to be used independently. Combining values from the two measurement systems can result in non-conformance with this Standard.
All references to gallons are to U.S. gallons.
For information on the unit conversion criteria used in this Standard, see Annex A.
2 Reference publications
This Standard refers to the following publications, and where such reference is made, it shall be to the
edition listed below, including all amendments published thereto.
CSA (Canadian Standards Association)
CAN/CSA-B1 25.3-05
Plumbing fittings
CAN/CSA-B651 -04
Accessible design for the built environment
C22.2 No. 0.1 5-01 (R2006)
Adhesive labels
ASME/CSA (American Society of Mechanical Engineers/Canadian Standards Association)
ASME A1 1 2.1 8.1 -2005/CAN/CSA-B1 25.1 -05
Plumbing supply fittings
ASME A1 1 2.1 8.2-2005/CAN/CSA-B1 25.2-05
Plumbing waste fittings
ASME A1 1 2.1 9.2-2008/CSA B45.1 -08
Ceramic plumbing fixtures
ASTM International (American Society for Testing and Materials)
C 282-99 (2005)
Standard Test Method for Acid Resistance of Porcelain Enamels (Citric Acid Spot Test)
C 346-87 (2004) e1
Standard Test Method for 45-deg Specular Gloss of Ceramic Materials
E 1 347-06
Standard Test Method for Color and Color-Difference Measurement by Tristimulus Colorimetry
F 462-79 (2007)
Standard Consumer Safety Specification for Slip-Resistant Bathing Facilities
