This Standard applies to portable power tools fordrilling, grinding， polishing, sawing, and drivingthreaded fasteners and hand tools for driving threadedfasteners. Other tools not classed as percussion tools belong in this category and may be added by revision oraddition through the usual procedure.
This Standard includes dimensions and tolerances forboth driving and driven elements where such coordination is important and not established by reference tothe pertinent American National Standards. All dimen.sions are in inches and millimeters.
percussion tools: hammers, chisels, scalers, tampers, claydiggers, and rock drills. Percussion tools are excludedfrom this Standard.
rounding values: when the next digit beyond the last digitto be retained is
(a) less than 5,the last digit to be retained is notchanged
(b) 5 or more, the last digit to be retained is increasedby one.
fool: as used in this Standard, a portable device for performing a mechanical operation with power from compressed air or electricity and hand operated.
3 NORMATIVE REFERENCES
The following is a list of publications referenced inthis Standard.ANSI B1.1-1989R01 Ed，Unified Inch Screw Threads(UN and UNR Thread Form)ANSI B7.1-2000, Safety Requirements for the Use, Careand Protection of Abrasive Wheels ANSI B92.1-1996,Involute Splines and InspectionPublisher: American National Standards Institute(ANSI), 25 West 43rd Street, New York,NY 10036ISO 117-1:1996，Assembly tools for screws and nuts -Driving squares – Part 1: Driving squares for handsocket tools
ISO 1174-2:1996,Assembly tools for screws and nuts -Driving squares – Part 2: Driving squares for powersocket toolsPublisher: International Organization for Standardiza-tion (ISO),1 rue de Varembe, Case Postale 56,CH1211 Geneve 20,Switzerland/Suisse
4 ISO COMPATIBILITY
Italicization and bold type indicate ISO compatibility.EXAMPLE:(38.214)
GAGE USE AND DESIGN
The illustrations shown herein are descriptive not restrictive, and not intended to preclude the manufacturerof products or gages which are otherwise in accordancewith this Standard.
Manufacturers may use gages with tighter dimensions or tolerances than shown herein to ensure product acceptance.
Tolerances on gage dimensions within the Standardrepresent new manufactured or purchased gage sizesThe extreme size for all limit (GO and NO GO) gagesshall not exceed the extreme limits of products specifiedwithin the Standard. All variations (manufacturing tol-erance, calibration error, wear allowance,etc.) in thegages, whatever their cause or purpose, shall bring thesegages within the extreme limits of this gage size specified within this Standard. Thus, a gage that representsa minimum limit may be larger, but never smaller, thanthe minimum specified for the product standard; like.wise, the gage that represents a maximum limit may besmaller, but never larger, than the maximum size specified for the product standard.
