ISO IEC 7810 pdf download Identification cards — Physical characteristics
1Scope
This International Standard is one of a series of standards describing the characteristics for identificationcards as defined in the definitions clause and the use of such cards for international interchange.
This International Standard specifies the physical characteristics of identification cards including cardmaterials, construction, characteristics,and dimensions for four sizes of cards.
ISOIEC 10373-1 specifies the test procedures used to check cards against the parameters specified in thislnternational Standard.
This International Standard specifies the requirements for cards used for identfication.lt takes intoconsideration both human and machine aspects and states minimum requirements.
lt is the purpose of this series of standards to provide criteria to which cards shall perform.No consideration isgiven within these standards to the amount of use, if any, experienced by the card prior to test. Failure toconform to specified criteria should be negotiated between the involved parties.
NOTE 1 Numeric values in the Sl and/or lmperial measurement system in this International Standard may have beenrounded off and therefore are consistent with, but not exactly equal to, each other. Either system may be used, but the twoshould not be intermixed or reconverted.The original design was made using the lmperial measurement system.
NOTE 2 A different standard for thin flexible cards exists. Thin flexible cards are not within the scope of thislnternational Standard.
2Conformance
An identification card is in conformance with this International Standard if it meets all mandatory requirementsspecified herein. Unless otherwise specified default values apply.
3 Normative references
The following referenced documents are indispensable for the application of this document. For datedreferences,only the edition cited applies.For undated references，the latest edition of the referenceddocument(including any amendments ) applies.
ISO/IEC 10373-1:1998, ldentification cards — Test methods — Part 1: General characteristics tests
NOTE The IlD-00 size card size was first defined by ENV 1375-1，ldentification card systems —Intersectorintegrated circuit(s) card additional formats — Part 1: ID-o00 card size and physical characteristics.
4Terms and definitions
For the purposes of this document, the following terms and definitions apply.
4.1
identification card
card identifying its holder and issuer which may carry data required as input for the intended use of the card and for transactions based thereon
4.2
signature panel
special area on the card intended to have a signature applied
4.3
warpage
deviation from flatness
4.4
normal use
use as an identification card (see 4.1) involving equipment processes appropriate to the card technology, and storage as a personal document between equipment processes
4.5
ID-1
nominally 85,60 mm (3.370 in) wide by 53,98 mm (2.125 in) high by 0,76 mm (0.030 in) thick
4.6
ID-2
nominally 105 mm (4.134 in) wide by 74 mm (2.913 in) high by 0,76 mm (0.030 in) thick
4.7
ID-3
nominally 125 mm (4.921 in) wide by 88 mm (3.465 in) high by 0,76 mm (0.030 in) thick
4.8
raised area
area whose surface is raised above that of the surrounding card surface by addition of some feature such as a hologram, signature panel, magnetic stripe, photograph, integrated circuit contacts, embossed characters
