IEC 62403 pdf download High density recording format on CD-R/RW disc systems – HD-BURN format
1 scope
This International Standard specifies the HD-BURN format applied to CD-R/RW discs. TheHD-BURN system is capable of recording the information in double density compared to theconventional CD-R/RW disc. It enables the realization of products with high reliability,highspeed and interchangeability, and is especially suitable for consumer applications with highcost-performance.
This document describes:
– the physical characteristics for the recording and playback;
– the track structure of a disc;
– the data structure in the track;
– logical format structure.
2Normative references
The following references are indispensable for the application of this document.For datedreferences,only the cited edition applies. For undated references,the latest edition of thereferenced document (including any amendments) applies.
IEC 60908,Audio recording -Compact disc digital audio system
ISO/IEC 16448:2002,Information technology – 120 mm DvD – Read-only disk
ISOIEC 20563,Information technology – 80 mm (1,23 Gbytes per side) and 120 mm (3,95Gbytes per side) DvD-recordable disc (DvD-R)
IEC 62291:2002,Multimedia data storage – Application program interface for UDF based filesystems
Iso 9660:1988,Volume and file structure of CD-ROM for Information Interchange
ISO/IEC 13346-1:1995,Information technology – Volume and file structure of write-once andrewritable media using non-sequential recording for information interchange – Part 1 : General
The Red Book: Compact disk digital Audio System Description Version,May 1999Sony/Philips
The Orange Book part2: Recordable compact disk systems,Part2 CD-R Version 3.1,Sony/Philips
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
absolute time in pre-groove
time-code information contained in the pre-groove with an additional modulation of the wobble
access guard area
preamble data area for reading the following ECC blocks
high-density write system at CD-R/RW disc
land pre pit
pits embossed on the land during the manufacture of the disc substrate, which contain address information
disc constituted by some sessions
non CD sector
sector, which has a different structure from the CD
physical sector number
serial number, which is allocated to physical sectors on the disc
guidance track in which clocking and time code information is stored by means of an FM modulated wobble
program memory data
information, which is described on the recording program of the disc, including information on each recording mode
3.1 0
program start information
start address of the first lead-in
