IEC 61888 pdf download Nuclear power plants – Instrumentation important to safety – Determination and maintenance of trip setpoints
1 Scope
This standard defines the requirements for assuring that automatic setpoints for nuclearsafety system instrumentation (as defined in clause 3), are established and maintained withinspecified limits in nuclear power plants and nuclear reactor facilities.
2Normative references
The following referenced documents are indispensable for the application of this document.For dated references, only the edition cited applies. For undated references, the latest editionof the referenced document (including any amendments) applies.
IEC 60050-394:1995, International Electrotechnical Vocabulary (IEV) – Chapter 394: Nuclearinstrumentation: lnstruments
IEC 60671, Periodic testing and monitoring of the protective system of nuclear reactors
IEC 61513:2001,Nuclear power plants – Instrumentation and control for system important tosafety – General requirements for systems
IAEA NS-R-1:2000,Safety of nuclear power plants: Design
For the purposes of this document, the following terms and definitions apply.
NOTE Additional definitions related to instrumentation terminology may be found in lEC 60050-394.
allowable value
a limit value that the trip setpoint may have when tested periodically,beyond whichappropriate action shall be taken
analytical limit (of setpoint)
limit of a measured or calculated variable established by the safety analysis to ensure thata safety limit is not exceeded. The margin between the analytical limit (of the setpoint) andthe safety limit allows to take into account:
– the response time of the instrument channel,
– the range of transients due to the considered accident.
as found
the condition in which a channel,or portion of a channel, is found after a period of operationand before recalibration (if necessary)
as left
the condition in which a channel,or portion of a channel, is left after calibration or finalsetpoint device setpoint verification
an undesired change in output over a period of time where change is unrelated to the input,environment, or load
the algebraic difference between the indication and the ideal value of the measured signal
final setpoint device
a component,or assembly of components,that provides input to the process voting logic foractuated equipment
NOTE Examples of final setpoint devices are bistables, relays,pressure switches, and level switches.
a device characteristic exhibited when a further change in the input produces an output signalthat reverses its direction from the specified input-output relationship
independent uncertainty
uncertainty components are independent of each other if their magnitudes or algebraic signsare not significantly correlated
3.1 0
instrument channel
an arrangement of components and modules, including sensor(s), as required to generate a single protective action signal when required by a plant condition
3.1 1
instrument channel range
the region between the limits within which a quantity is measured, received, or transmitted. Is expressed by stating the lower and upper instrument channel range values.
