1 Scope
This International Standard specifies the requirements of solderable enamelled round copperwinding wire of class 130 with a sole coating based on polyurethane resin,which may bemodified provided it retains the chemical identity of the original resin and meets all specifiedwire requirements.
NOTE A modified resin is a resin that has undergone a chemical change, or contains one or more additives toenhance certain performance or application characteristics.
Class 130 is a thermal class that requires a minimum temperature index of 130 and a heatshock temperature of at least 155 °c.
The temperature in degrees Celsius corresponding to the temperature index is not necessarilythat at which it is recommended that the wire be operated and this will depend on manyfactors,including the type of equipment involved.
The range of nominal conductor diameters covered by this standard is:- Grade 1 : 0,018 mm up to and including 2,000 mm;
-Grade 2: 0,020 mm up to and including 2,000 mm.
The nominal conductor diameters are specified in clause 4 of IEC 60317-O-1.
2Normative references
The following standard contains provisions which,through reference in this text,constituteprovisions of this International Standard.At the time of publication, the edition indicated wasvalid. All standards are subject to revision,and parties to agreements based on thisInternational Standard are encouraged to investigate the possibility of applying the mostrecent edition of the standard indicated below. Members of lEC and lSO maintain registers ofcurrently valid international standards.
IEC 60317-0-1:1990,Specifications for particular types of winding wires – Part 0: Generalrequirements – Section ‘1: Enamelled round copper wire
3 Definitions and general notes on methods of test
For definitions and general notes on methods of test see clause 3 of lEC 60317-O-1.
In case of inconsistencies between lEC 60317-0-1 and this standard,IEC 60317-4 shallprevail.
4 Dimensions
See clause 4 of IEC 6031 7-0-1 .
5 Electrical resistance
See clause 5 of IEC 6031 7-0-1 .
6 Elongation
See clause 6 of IEC 6031 7-0-1 .
7 Springiness
See clause 7 of IEC 6031 7-0-1 .
8 Flexibility and adherence
See clause 8 of IEC 6031 7-0-1 , where the constant K used for the calculation of the number of revolutions for the peel test shall be 1 50 mm.
9 Heat shock
See clause 9 of IEC 6031 7-0-1 , where the minimum heat shock temperature shall be 1 55 °C.
1 0 Cut-through
No failure shall occur within 2 min at 1 70 °C.
1 1 Resistance to abrasion (nominal conductor diameters from 0,250 mm up to and including 2,000 mm)
The wire shall meet the requirements given in table 1 .
