IEC 60255-5 pdf download Electrical relays – Part 5: Insulation coordination for measuring relays and protection equipment – Requirements and tests
1 Scope and object
This part of IEC 60255 gives general requirements for the insulation coordination ofmeasuring relays and protection equipment.
NOTE 1 Unless otherwise stated,the term “relay(s)” is used as an abbreviation for the expression “measuringrelays and protection equipment” in this standard.
In particular, this standard, specifies the following:definition of terms;
guidance for the selection of clearances and creepage distances and other aspectsrelated to the insulation of measuring relays and protection equipment;
– requirements for voltage tests and insulation resistance measurement.
This standard is applicable to the installation and use at altitudes up to 2 000 m of equipmenthaving a rated a.c. voltage up to 1 000 v, with a rated frequency up to 65 Hz, or a d.c.voltageup to 1 500 v.
This standard also applies to associated auxiliary devices such as shunts,series resistors,transformers,etc., used and tested together with measuring relays and protection equipmentas mentioned above,except where the devices are covered by other iEC publications,forexample communication interfaces.
NOTE 2 Requirements for altitudes exceeding 2 000 m can be derived from table B.1.
2Normative references
The following normative documents contain provisions which,through reference in this text,constitute provisions of this part of lEC 60255. For dated references,subsequentamendments to,or revisions of, any of these publications do not apply.However, parties toagreements based on this part of lEC 60255 are encouraged to investigate the possibility ofapplying the most recent editions of the normative documents indicated below. For undatedreferences, the latest edition of the normative document referred to applies. Members of lSOand lEC maintain registers of currently valid lnternational Standards.
IEC 60050(151):1978,International Electrotechnical Vocabulary (IEV) – Chapter 151: Electricaland magnetic devices
IEC 60050(448):1995,International Electrotechnical Vocabulary – Chapter 448: Power systemprotection
IEC 60060-1:1989,High-voltage test techniques – Part 1: General definitions and testrequirements
IEC 60085:1984,Thermal evaluation and classification of electrical insulation
IEC 60255 (all parts),Electrical relays
IEC 60255-21-1:1988,Electrical relays – Part 21: Vibration, shock, bump and seismic tests onmeasuring relays and protection equipment – Section 1: Vibration tests (sinusoidal)
IEC 60255-21-2:1988,Electrical relays – Part 21: Vibration, shock, bump and seismic tests onmeasuring relays and protection equipment – Section 2: Shock and bump tests
IEC 60255-21-3:1993,Electrical relays – Part 21: Vibration,shock, bump and seismic tests onmeasuring relays and protection equipment – Section 3: Seismic tests
IEC 60664-1:1992,Insulation coordination for equipment within low-voltage systems – Part 1:Principles,requirements and tests
IEC 61000-4-5:1995,Electromagnetic compatibility (EMC) – Part 4:Testing and measurementtechniques – Section 5: Surge immunity test
IEC 61180-1:1992,High-voltage test techniques for low-voltage equipment – Part 1:Definitions and test procedure requirements
IEC 61180-2:1994,High-voltage test techniques for low-voltage equipment – Part 2: Testequipment
For the purpose of this part of lEC 60255, the following definitions together with those ofIEC 60050(448),IEC 60664-1 and the relevant parts of lEC 60255 apply.
hazardous live part
part at a voltage in excess of 50 v r.m.s. or 75 v d.c.
exposed conductive part
conductive part which can be readily touched and is normally not hazardous live but may beat hazardous live voltage under a single fault condition
NOTE1 For relays which are not enclosed, the frame, the fixing devices, etc., form the exposed conductive parts.NOTE2 For relays which are enclosed, the conductive parts which are accessible when the relay is mounted inits normal position of use, including those of its fixing surface, form the exposed conductive parts.Small parts suchas inscription plates, screws and rivets which are isolated from the circuits are not taken into consideration.
