DD IEC PAS 61076-2-108 pdf download Connectors for electronic equipment — Product requirements — Part 2-108: Circular connectors — Detail specification for glass to metal seal style M12 connectors with screw-locking intended to mate with connectors conforming to IEC 61076-2-101
1.1scope
This PAS describes circular connectors M12typically used for industrial processmeasurement and control.These connectors consist of fixed glass to metal sealed styles withrewireable male contacts. Female connectors have round contacts 0,6 mm, 0,76 mm,0,8 mm and 1,0 mm.
The different codings prevent the mating of these coded male or female connectors to anyother interfaces and cross-mating between the different codings.
NOTE M12 is the dimension of the thread of the screw locking mechanism of these circular connectors.1.2Recommended method of termination
The contact terminations shall be of the following types: Eyelet,solder PCB,rounded orcrimp.
1.2.1 Number of contacts or contact cavities
The number of contacts or contact cavities shall be in accordance with 1.2.1 ofIEC61076-2-101.
1.3 Ratings and characteristics
The ratings and characteristics shall be in accordance with 1.3 of lEC 61076-2-101.
1.4 Normative references
The following referenced documents are indispensable for the application of this document.For dated references, only the edition cited applies.For undated references, the latest editionof the referenced document (including any amendments) applies.
IEC 60050-581,International Electrotechnical Vocabulary (IEV) – Part 581:Electromechanicalcomponents for electronic equipment
IEC 60512 (all parts),Connectors for electronic equipment – Tests and measurements
IEC 61076-1:2006,Connectors for electronic equipment – Product requirements – Part 1:Generic specification
IEC 61076-2-101:2008,Connectors for electronic equipment – Product requirements -Part 2-101:Circular connectors – Detail specification for M12 connectors with screw-locking
IEC 61984:2008,Connectors – Safety requirements and tests
1 .5 Marking
The marking of the connector and the package shall be in accordance with 2.7 of IEC 61 076-1 .
1 .6 IEC Type designation
1.7Ordering information
For ordering connectors to this standard, the type designation described in 1.6 shall be used.
Example 1: Glass to metal seal fixed connector YM 004 -HB1-A: Fixed connector Style YM,glass to metal seal, jam nut rear mounting, male contacts with 5 mm long PCB terminations,4way, gold contact finish, coding A.
1.8Safety aspects
For safety aspects lEC 61984 shall be considered unless otherwise specified.
Technical information
2.1Terms and definitions
For the purposes of this document, the terms and definitions given in lEC 60050-581 apply aswell as the following.
2.1.1
glass to metal seal
a form of construction whereby the connector contacts are housed in a glass insert which isinside a metal connector shell so as to form a connector with a hermetic seal which may usedto isolate differing environments
2.1.2
matched glass to metal seal
a form of construction whereby the thermal expansion characteristics of the glass, the metalliccontacts,and the connector shell are similar and the seal between the glass and the metal isformed by a chemical bond
