ISO 16425 pdf download Ships and marine technology — Guidelines for the installation of ship communication networks for shipboard equipment and systems
This International Standard specifies installation guidelines for ship communication networks forimproving communication for shipboard equipment and systems that are independentfrom navigationalequipment networks and engine-control networks.
This International Standard utilizes existing standards relating to protocols, and provides newguidelines for such aspects as communication network-system architecture, administration, operationand installation.
The new guidelines specifically include: redundancy if necessary for a shipboard communicationnetwork system; network adminstration that does not require experts: physical as well as logicasecurity; and networkinstallation.
2 Normative references
The following documents, in whole or in part, are normatively referenced in this document and areindispensable for its application. For dated references, only the edition cited applies. For undatedreferences, the latest edition of the referenced document (including any amendments) applies.
IEC 61162-450,Maritime navigation and radio communication equipment and systems – Digitalinterfaces – Part 450: Multiple talkers and multiple listeners – Ethernet interconnection
IEEE 802.3, Ethernet (Formerly: Carrier Sense Multiple Access with Collision Detection)
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply
networkcommunication network restricted in scope to a ship
eXtensible Markup Languagemetalanguage for sendingand receiving dataviaanetworkthatis recommendedbythe WWW Consortium
gatewaycommunication device that connects computer networks to networks with differing protocols
domain in a computer network where simultaneous transmission will cause collisions or congestion
domain on a computer network where broadcasted frames (broadcasts) are received
spanning tree protocol
method of control in a loop topology network for preventing data from entering endless loops
protocol for sending and receiving information via the Internet
OSI reference model
Open Systems Interconnection reference model
model that divides the communication functions stipulated for computers by the International Organization for Standardization into layers
Simple Network Management Protocol
communication rules that define methods for communicating information in order to monitor and control network devices on network
Internet Control Message Protocol
communication rules that are used for such purposes as notifications of errors in the processing of datagrams, and notifications of information relating to communication
