IEC TS 62239 pdf download Process management for avionics – Preparation of an electronic components management plan
1 Scope
This Technical Specification defines the requirements for developing an ElectronicComponents Management Plan (ECMP) to assure customers and regulatory agencies that allof the electronic components in the equipment of the plan owner are selected and applied incontrolled processes compatible with the end application and that the technical requirementsdetailed in Clause 4 are accomplished. In general，the owners of a complete electroniccomponents management plan are avionics equipment manufacturers.
2Normative references
The following referenced documents are indispensable for the application of this document.For dated references, only the edition cited applies.For undated references, the latest editionof the referenced document (including any amendments) applies.
IEC 61340-5-1:2007,Electrostatics – Part 5-1: Protection of electronic devices from electro-static phenomena – General requirements
IEC/TR 61340-5-2:2007，Electrostatics – Part 5-2: Protection of electronic devices fromelectrostatic phenomena – User guide
IEC/TR 62240，Process management for avionics – Use of semiconductor devices outsidemanufacturers” specified temperature range
IEC/TS 62396 (all parts), Process management for avionics – Atmospheric radiation effectsIEC 62402:2007,Obsolescence management – Application guide
JEP149 (Nov 2004)，JEDEC Publication，JEDEC Standard Application Thermal DeratingMethodologies
JESD47,JEDEC Standard,Stress – Test-Driven Qualification of integrated circuits
JESD94.01,JEDEC Standard，Application Specific Qualification Using Knowledge Based TestMethodology
MIL-HDBK-263, Revision B Electrostatic Discharge Control Handbook
AEC-Q100, Failure Mechanism based Stress Test Qualification for lIntegrated Circuits
AEC-Q101,Stress Test Qualification for Automotive Grade discrete Semiconductors
AEC-Q200,Stress Test Qualification for Passive components
3 Terms, definitions and abbreviations
3.1 Terms and definitions
For the purposes of this document, the following definitions apply.
NOTE Plan owners may use alternative definitions consistent with convention within their company in their plan.
3.1.1
avionics equipment environment
applicable environmental conditions (as described per the equipment specification) that the equipment shall be able to withstand without loss or degradation in equipment performance throughout its manufacturing cycle and maintenance life (the length of which is defined by the equipment manufacturer in conjunction with customers)
3.1.2
capable
term used to indicate that a component can be used successfully in the intended application
3.1.3
certified
indicates assessment and compliance to an applicable third party standard and maintenance of a certificate and registration (i.e. JAN, IECQ)
3.1.4
characterization
process of testing a sample of components to determine the key electrical parameter values that can be expected of all produced components of the type tested
3.1.5
component application
process that assures that the component meets the design requirements of the equipment in which it is used
3.1.6
component manufacturer
organization responsible for the component specification and its production
