IEC TR 62602 pdf download Conductors of insulated cables – Data for AWG and KCMIL sizes
1 Scope
IEC/TR 62602, which is a technical report, specifies the nominal cross-sectional areas, in the range 20 AWG to 2 000 kcmil (0,52 mm 2 to 1 01 0 mm 2 ), for conductors in electric power cables and cords for a wide range of types. Requirements for numbers and sizes of wires and resistance values are also included. These conductors include solid and stranded copper, aluminium and aluminium alloy conductors in cables for fixed installations and flexible copper conductors.
This technical report is not intended to apply to conductors designed for use in cables intended for telecommunication or data transmission, winding wires or similar products.
Unless indicated to the contrary in a particular clause, this technical report relates to conductors in finished cables and not to conductors made or supplied for inclusion into a cable.
The annexes give supplementary information covering measurement of resistance (Annex A),temperature correction factors for resistance measurement (Annex B) and dimensional limits of circular conductors (Annex C).
2 Terms and definitions
For the purposes of this document, the following definitions apply.
2.1
metal-coated
coated with a thin layer of suitable metal, such as tin or tin alloy
2.2
nominal cross-sectional area
value that identifies a particular size of conductor but is not subject to direct measurement
NOTE Each particular size of conductor in this technical report is required to meet a maximum resistance value.
3 Classification
The conductors have been divided into four classes, 1 , 2, 5 and 6. Those in Classes 1 and 2 are intended for use in cables for fixed installations. Classes 5 and 6 are intended for use in flexible cables and cords but may also be used for fixed installations:
– Class 1 : solid conductors;
– Class 2: stranded conductors;
– Class 5: flexible conductors;
– Class 6: flexible conductors which are more flexible than Class 5.
4 Materials
4.1 General
The conductors consist of one of the following:
• plain or metal-coated annealed copper;
• aluminium or aluminium alloy.
4.2 Solid aluminium conductors
Circular and shaped solid aluminium conductors are made from aluminium such that the tensile strength of the completed conductor is within the following limits:
NOTE The values given above are not applicable to aluminium alloy conductors.
4.3 Circular and shaped stranded aluminium conductors
Stranded aluminium conductors are made from aluminium such that the tensile strength of the individual wires is within the following limits:
NOTE 1 The values given above are not applicable to aluminium alloy conductors.
NOTE 2 This data can only be checked on wires taken before stranding and not on wires taken from a stranded conductor.
5 Solid conductors and stranded conductors
5.1 Solid conductors (Class 1)
5.1.1 Construction
a) Solid conductors (Class 1 ) consist of one of the materials specified in Clause 4.
b) Solid copper conductors are of circular cross-section.
