IEC PAS 62633 pdf download Industrial communication networks – Profiles – Additional Fieldbus profiles for real-time networks based on ISO/IEC 8802-3 – SNpTYPE
1 Scope
This Clause is identical in form and content for all CPFs to that of IEC 61 784-2:2007.
2 Normative references
The following referenced documents are indispensable for the application of this document.
For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies.
This Clause is identical in form and content for all CPFs to that of IEC 61 784-2:2007.
IEC 61 784-2:2007, Industrial communication networks – Profiles – Part 2: Additional fieldbus profiles for real-time networks based on ISO/IEC 8802-3
3 Terms, definitions, abbreviated terms, acronyms, and conventions
3.1 Terms and definitions
For the purposes of this document, the following terms and definitions apply, in addition to those of IEC 61 784-2:2007.
3.1 .30
real time frame line (RTFL)

communication model for communication with high real time requirements
3.1 .31
real time frame network (RTFN)

communication model for communication with low real time requirements
3.2 Abbreviated terms and acronyms
The following additional abbreviated terms and acronyms for CPF SNpFAMILY apply, in addition to those of IEC 61 784-2:2007.
RTFL Real time frame line
RTFN Real time frame network
3.3 Symbols
The following additional subclause for the symbols of the new CPF SNpFAMILY applies, in addition to those of IEC 61 784-2:2007.
7 Communication Profile Family SNpFAMILY (SafetyNET p 1 ) – RTE
communication profiles
7.1 General overview
Communication Profile Family SNpFAMILY defines profiles based on IEC/PAS 61 1 58-3-22 through IEC/PAS 61 1 58-6-22.
In this part of IEC 61 784, the following communication profiles are specified for CPF SNpFAMILY.
• Profile SNpFAMILY/1
This profile defines protocol and service selection for devices which utilize the communication model real time frame line (RTFL).
• Profile SNpFAMILY/2
This profile defines protocol and service selection for devices which utilize the communication model real time frame network (RTFN).
7.2 Profile SNpFAMILY/1
7.2.1 Physical layer
The physical layer shall be based on standard Ethernet hardware according to ISO/IEC 8802-3.
CP SNpFAMILY/1 devices shall use a data rate of 1 00 Mbit/s and full-duplex transmission mode. A combination of full-duplex and 1 00Base-TX with auto crossover function (wire, 2 twisted pairs) should be used.
When using cables, they shall be rated Cat5e or better, and shielded in an appropriate way (FTP, STP or SFTP) depending upon EMC constraints.
7.2.2 Data link layer
Data link layer is described in IEC/PAS 61 1 58-3-22 and IEC/PAS 61 1 58-4-22. Table 1 specifies the use of the services included in this profile. Table 2 specifies the use of the protocol included in this profile.
