IEC 62208 pdf download Empty enclosures for low-voltage switchgear and controlgear assemblies – General requirements
This International Standard applies to empty enclosures,prior to the incorporation ofswitchgear and controlgear components by the user, as supplied by the enclosuremanufacturer.
This standard specifies definitions,classifications,characteristics and test requirements ofenclosures to be used as part of switchgear and controlgear assemblies in accordance with theIEC 60439 series, the rated voltage of which does not exceed 1 000 V a.c. at frequencies notexceeding 1 000 Hz,or 1 500 v d.c. and suitable for general use for either indoor or outdoorapplications.
This standard does not apply to enclosures,which are covered by other specific productsstandards (e.g.IEC 6067o).
Compliance with the safety requirements of the applicable product standard is the responsibilityof the final assembly manufacturer.
NOTE This standard may serve as a basis for other technical committees.
2 No rmative refe re nces
The following referenced documents are indispensable for the application of this document.Fordated references,only the edition cited applies. For undated references,the latest editionof the referenced document (including any amendments) applies.
lEC 60068-2-2:1974,Basic environmental testing procedures – Part 2: Tests – Tests B:Dry heat Amendment 2 (1994)
lEC 60068-2-11:1981,Basic environmental testing procedures – Part 2: Tests – Test ka:Salt mist
IEC 60068-2-30:1980,Basic environmental testing procedures – Part 2: Tests – Test Db andguidance: Damp heat, cyclic (12+ 12 hour cycle) Amendment 1 (1985)
IEC 60068-2-75:1997,Environmental testing – Part 2: Tests -Test Eh: Hammer tests
lEC 60439(all parts),Low-voltage switchgear and controlgear assemblies
IEC 60439-1:1999,Low-voltage switchgear and controlgear assemblies – Part 1 : Type-testedand partially type-tested assemblies
IEC 60439-5:1996,Low-voltage switchgear and controlgear assemblies – Part 5: Particularrequirements for assemblies intended to be installed outdoors in public places – Cabledistribution cabinets (CDCs) for power distribution in networks
IEC 60529:1989, Degrees of protection provided by enclosures (IP code)
ISO 11469:2000, Plastics – Generic identification and marking of plastic products
3 Terms and definitions
For the purposes of this International Standard, the following definitions apply.
empty enclosure
enclosure intended for support and installation of electrical equipment, whose internal space provides suitable protection against external influences as well as a specified degree of protection against approach to or contact with live parts and against contact with moving parts
NOTE Throughout this standard, the word enclosure is used for empty enclosure.
protected s pace
internal space or portion of the internal space of the enclosure as specified by the manufacturer intended for the mounting of switchgear and controlgear for which the specified protection is provided by the enclosure
external part of the enclosure
hinged or sliding cover
mounting plate
separate internal accessory of the enclosure intended for the mounting of electrical components
cable gland plate
removable accessory of the enclosure, intended for securing and sealing of cables, conductors and conduits at their point of entry
