IEC 62148-5 pdf download Fibre optic active components and devices – Package and interface standards – Part 5: SC 1×9 fibre optic modules
1 scope
This part of lEC 62148 covers the physical interface specifications for the SC 1×9 fibre opticmodule family.
2Normative references
The following referenced documents are indispensable for the application of this document.Fordated references,only the edition cited applies. For undated references, the latest edition ofthe referenced document (including any amendments) applies.
IEC 61754-4,Fibre optic connector interfaces – Part 4 : Type sc connector family
IEC 62148-1,Fibre optic active components and devices: Package and interface standards -Part 1: General and guidance
3 Definitions and abbreviations
For the purpose of this International Standard, the following abbreviation and definition apply.
3.1 Definition
fibre optic module
module that converts one or more electrical signals into one or more optical signals,or viceversa, and that is connected to at least one optical fibre
PCB: printed circuit board
4 Classification
The fibre optic module described in this standard is classified as type 1 according to thedefinitions of IEC 62148-1.
5 Specification of the optical interface
5.1 Optical connector interface
This standard applies to the SC duplex optic connector interface, which is specified in IEC 61 754-4.
5.2 Optical port assignment
Optical port numbering assignments are shown in Figure 1 .
