IEC 60872-3 pdf download Maritime navigation and radiocommunication equipment and systems – Radar plotting aids – Part 3: Electronic plotting aid (EPA) – Performance requirements – Methods of testing and required test results
1 Scope
This part of lEC 60872 specifies the minimum operational and performance requirements,methods of testing and test results for equipment that complies with performance standards notinferior to those adopted by the International Maritime Organization (iMO) in resolution MSC.64(67) Annex 4 – Appendix 2. In addition,this standard takes account of lMO Resolution A.694and is associated with lEC 60945.
When a requirement in this standard is different from lEC 60945, the requirement in thisstandard takes precedence.
The electronic plotting aid for manual direct plotting is intended for small ships fitted with eithera gyrocompass or a transmitting marine electromagnetic compass conforming to lSO 11606 ora transmitting magnetic heading device conforming to lMO MSC.86(70) – annex 2, and a speedand distance measuring equipment(SDME) conforming to lMO Resolution A.824 andIEC 61023.This plotting aid is not suitable for ships classed as high-speed craft.
All texts in this standard, the wording of which is identical to that in lIMO resolution MSC.64(67)Annex 4 – Appendix 2, are printed in italics and the resolution and paragraph numbers areindicated in brackets.
Normative references
The following normative documents contain provisions which，through reference in this text,constitute provisions of this part of lEC 60872.For dated references,subsequent amendmentsto，or revisions of，any of these publications do not apply.However，parties to agreementsbased on this part of lEc 60872 are encouraged to investigate the possibility of applying themost recent editions of the normative documents indicated below. For undated references, thelatest edition of the normative document referred to applies. Members of lEC and lSO maintainregisters of currently valid International Standards.
IEC 60872-1:1998，Maritime navigation and radiocommunication equipment and systems -Radar plotting aids – Part 1: Automatic radar plotting aid(ARPA) – Methods of testing andrequired test results
IEC 60872-2:1999，Maritime navigation and radiocommunication equipment and systems -Radar plotting aids – Part 2:Automatic tracking aid (ATA) – Methods of testing and requiredtest results
lEC 60936-1:1999，Maritime navigation and radiocommunication equipment and systems -Radar – Part 1: Shipborne radar – Performance requirements – Methods of testing and requiredtest results
lEC 60945:1996，Maritime navigation and radiocommunication equipment and systems -General requirements – Methods of testing and required test results
IEC 61023:1999，Maritime navigation and radiocommunication equipment and systems -Marine speed and distance measuring equipment(SDME) – Performance requirements -Methods of testing and required test results
IEC 61162(all parts)，Maritime navigation and radiocommunication equipment and systems -Digital interfaces
ISO:11606,Ships and marine technology – Marine electromagnetic compassesIso 9o00 (all parts),Quality management and quality assurance standards
IMO Resolution A.694:1991,General requirements for shipborne radio equipment forming partof the global maritime distress and safety system (GMDSs) and for electronic navigational aids
IMO Resolution A.823:1995, Performance standards for automatic radar plotting aids (ARPAs)IMO Resolution A.824:1995,Performance standards for devices to indicate speed and distance
IMO MSC/Circular 603:1993，Guidelines on display sizes and techniques for navigationalpurposes
IMO MSC.64(67):1996,Annex 4 – Performance standards for radar equipment, and Appendix 2- Electronic plotting aids
IMO MSC.86(70):1998,Annex 2 – Performance standards for marine transmitting magneticheading devices (TMHDs)
lHO S-52: 1996,Specifications for chart content and display aspects of ECDIS
