IEC 60749-37 pdf download Semiconductor devices – Mechanical and climatic test methods – Part 37: Board level drop test method using an accelerometer
4 Test apparatus and components
4.1 Test apparatus
The shock-testing apparatus shall be capable of providing shock pulses up to a peak acceleration of 2 900 m·s –2 with a pulse duration between 0,3 ms and 8,0 ms to the body of the device and a velocity change of 71 0 mm·s –1 to 5 430 mm·s –1 .
The acceleration pulse shall be a half-sine waveform with an allowable deviation from specified acceleration level not greater than ±20 % of the specified peak acceleration. This is determined by a transducer having a natural frequency 5 times the frequency of the shock pulse being established and measured through a low pass filter having a band width preferably at least 5 times the frequency of the shock pulse being established. It is very important that the transducer resonance does not approach the measured value. Filtering should not be used in lieu of good measurement set-up and procedure practices. The pulse duration shall be measured between the points at 1 0 % of the peak acceleration during rise time and 1 0 % of the peak acceleration during decay time. Absolute tolerances of the pulse duration shall be ±30 % of the specified duration. It is recommended that the test velocity change should be ±1 0 % of the specified level.
4.2 Test components
This standard covers all area arrays and perimeter-leaded surface-mountable packaged semiconductor devices such as ball grid arrays (BGA), land grid arrays (LGA), chip scale packages (CSP), thin small outline packages (TSOP) and quad flat no-lead packages (QFN) typically used in handheld electronic product. All components used for this testing must be daisy-chained. The daisy chain should either be made at the die level or by providing daisy chain links at the lead-frame or substrate level. In case of non-daisy chain die, a mechanical dummy die shall be used inside the package to simulate the actual structure of the package. The die size and thickness should be similar to the functional die size to be used in application. The component materials, dimensions and assembly processes shall be representative of typical production device.
4.3 Test board
Since the drop test performance is a function of the test board used for evaluation, this standard describes a preferred test board construction, dimensions, and material that is representative of those used in handheld electronic products. If another board construction/material better represents a specific application, the test board construction, dimensions and material should be documented. The test data generated using such a board shall be correlated at least once by generating the same data on the same component using the preferred board defined in this document (see Annex A for recommendations).
