IEC 60245-1 pdf download Rubber insulated cables – Rated voltages up to and including 450/750 V – Part 1: General requirements
1 General
1.1scope
This part of lEC 60245 applies to rigid and flexible cables with insulation, and sheath if any,based on vulcanized rubber of rated voltages u,/u up to and including 450/750 V used inpower installations of nominal voltage not exceeding 450/750 V a.c.
NOTE For some types of flexible cables the term ‘cord’ is used.
The particular types of cables are specified in lEC 60245-3，IEC 60245-4，etc.
The codedesignations of these types of cables are given in Annex A.
The test methods specified in Parts 1 to 8 are given in lEC 60245-2,IEC 60332-1 and in therelevant parts of lEC 60811.
1.2 Normative references
The following referenced documents are indispensable for the application of this document.For dated references, only the edition cited applies. For undated references, the latest editionof the referenced document (including any amendments) applies.
IEC 60173:1964,Colours of the cores of flexible cables and cordsIEC 60228:1978,Conductors of insulated cables
IEC 60245-2:1994, Rubber insulated cables – Rated voltages up to and including 450/750 V-Part 2: Test methods
IEC 60245-3:1994,Rubber insulated cables – Rated voltages up to and including 450/750V-Part 3: Heat resistant silicone insulated cables
IEC 60245-4:1994,Rubber insulated cables – Rated voltages up to and including 450/750 V-Part 4: Cords and flexible cables
IEC 60245-7:1994, Rubber insulated cables – Rated voltages up to and including 450/750V-Part 7: Heat resistant ethylene-vinyl-acetate rubber insulated cables
IEC 60332-1:1993,Tests on electric cables under fire conditions – Part 1: Test on a singlevertical insulated wire or cable
IEC 60811-1-1:1993,Common test methods for insulating and sheathing materials of electriccables – Part 1: Methods for general application – Section 1: Measurement of thickness andoverall dimensions – Tests for determining the mechanical properties
IEC 60811-1-2:1985,Common test methods for insulating and sheathing materials of electriccables – Part 1: Methods for general application – Section Two: Thermal ageing methods
IEC 60811-1-4:1985, Common test methods for insulating and sheathing materials of electriccables – Part 1: Methods for general application – Section Four: Tests at low temperature
IEC 60811-2-1:1998,Insulating and sheathing materials of electric and optical cables -Common test methods – Part 2-1: Methods specific to elastomeric compounds – Ozoneresistance, hot set andmineral oil immersion tests
IEC 60811-3-1:1985,Common test methods for insulating and sheathing materials of electriccables – Part 3: Methods specific to PVC compounds -Section One: Pressure test at hightemperature – rests for resistance to cracking
Terms and definitions
For the purposes of this document, the following terms and definitions apply:
2.1 Definitions relating to insulating and sheathing materials
2.1.1
type of compound
category in which a compound is placed according to its properties, as determined by specifictests
NOTE The type designation is not directly related to the composition of the compound.
2.1.2
rubber compound
combination of materials suitably selected, proportioned, treated and vulcanized, of which thecharacteristic constituent is a rubber and/or synthetic elastomer
NOTE Vulcanization is defined as a post-application treatment taking place after the insulation andlor sheath hasbeen applied in order to induce permanent cross-linking of the elastomer.
2.1.3
polychloroprene compound (PCP) or other equivalent synthetic elastomer
vulcanized compound in which the elastomer is polychloroprene or other equivalent syntheticelastomer providing a compound with properties similar to PCP
2.1.4
ethylene-vinyl acetate rubber compound(EVA) or other equivalent synthetic elastomercross-linked compound in which the elastomer is ethylene-vinyl acetate or other equivalentsynthetic elastomer providing a compound with properties similar to EVA
