IEC 60068-2-53 pdf download Environmental testing – Part 2-53: Tests and guidance – Combined climatic (temperature/humidity) and dynamic (vibration/shock) tests
Specimens may be repositioned for shock or vibration along another axis at standard climatic conditions according to IEC 60068-1 , as required by the relevant specification. The dynamic test shall be continued when the required test temperature and humidity has been reached.
3.2 Temperature information
If cold or dry heat testing is required, the exposure time shall not commence until all parts of the specimen have reached a temperature within at least 3 K of the working space temperature. For heat-dissipating specimens, the period of exposure shall not begin until the temperature of the specimens changes not more than 1 K within 1 h at the stabilized working space temperature. The last hour of the temperature-soaking time shall be considered to be the first hour of the exposure period.
If a damp heat constant testing is required, the exposure time shall not commence until all parts of the specimen have reached a temperature within at least 3 K of the temperature, and a relative humidity within 3 % of the humidity, within the working space of the test chamber. For heat-dissipating specimens, the period of exposure shall not begin until the temperature of the specimens changes not more than 1 K within 1 h at the stabilized working space temperature. The last hour of the temperature-soaking time shall be considered to be the first hour of the exposure period.
If slow temperature change test or damp heat cyclic test is performed, the required exposure time starts with the beginning of temperature change.
If the specimen is mounted on shock absorbers, time shall be given for temperature stabilization of the absorber elements.
3.3 Dynamic test information
The relevant specification shall contain dynamic test information. The dynamic test information includes following details (see also Clause 5):
a) identification of dynamic test ( such as sinusoidal, random, mixed mode vibration or impact);
b) severities of dynamic stress;
c) axis and directions of dynamic stress;
d) duration and timing of dynamic stress (see Annex A);
e) IEC 60068-2-47 shall be referred to concerning mounting of specimen;
f) other details specified in the reference standards.
3.4 Initial measurement and functional performance test
The specimen shall be submitted to the visual, dimensional, functional and any other checks prescribed by the relevant specification.
3.5 Operating condition of specimen
In the case of electrically-operated specimens, the times at which the power supply shall be powered on or off and the voltage of the power supply within each temperature cycle shall be specified in the relevant specification. The times at which other functions such as cooling, heating and various loads are switched on or off shall be stipulated in the relevant specification or controlled by a special type of test equipment.
